QPOL 300 A1-ECO

The Qpol 300 A1-ECO+ is a single-wheel grinding and polishing machine for the metallographic laborator

Categories:
Manual Grinder & Polisher, Grinders & Polishers

Description
Details
Materials
Documents
Videos
Review

Description

PRODUCT ADVANTAGES

• Single wheel grinder / polisher for metallographic sample preparation
• Spin cycle feature (Cleaning Boost)
• 4.3″ Touch-Screen with intuitive QATM user software
• 200 customized programs storable
• Easy cleaning/rinsing of bowl by lifting the working wheel (single-disc design)
• Variable speed of working wheel and polishing head
• Working wheel and polishing head: clockwise / counter-clockwise rotation
• Impact-proof plastic bowl
• Aluminium case, powder coated
• Economic LED illumination

FEATURES

The ECO grinding & polishing head with adjustable swivelling limits is equipped with recessed grips on both sides and integrated buttons for easy swivelling and adjustment. A large gap between the working surface and the polishing head ensures convenient changing of the sample holder.

After removal of the splash protection ring, the working wheel is freely accessible. The wheel is automatically arrested when placed on the new mounting system. On lifting the wheel, all parts below are accessible for easy cleaning.

The ECO polishing head is equipped with LED illumination of the working area and a holder for the nozzles of the Qdoser ECO dosing system. Water is supplied automatically via the head.

QATM offers a wide selection of standard sample holders in various diameters and for different applications and machines. Samples with unusual dimensions can be clamped with the help of special design sample holders.

The automatic grinders and polishers can be combined with the fully automatic dosing system Qdoser ECO or the manual dosing solution Qdoser One, thus offering a high degree of flexibility for sample preparation and ease of use.

PROTECTIVE HOOD (OPTIONAL)

The optional protective hood for grinding and polishing machines of the Qpol 250/300 series is available in 2 versions:

Variant 1: transparent hood for access and splash protection with connection for external exhaust system.

Variant 2: with additional automatic locking during the grinding and polishing process

Brand QATM
Working wheels ø 250/300 mm
No. of samples (single pressure) 1-6 samples ø 50 mm
Single pressing force variable, 5-80 N
Central pressing force variable, 20-350 N
Connection power 2.8 kVA
Drive power (grinder) 0.75 kW (S1)
Drive power (head) 0.18 kW (S1)
Speed (grinder) 30 - 600 min-1
Speed (head) 30 - 160 min-1
W x H x D 511 x 530-610 x 710 mm / 20.12 x 20.87-24.02 x 27.95 in
Weight ~ 64 kg
Water connection 1x fresh water connection R½" max. 6 bars
Dosing system (option) Qdoser ECO / ECO+

Documents

Download Brochure QPOL 300 A1-ECO
