UltiMaker PVA Removal Station
$1,095
Efficient 3D Printing Support Removal Tool.
- Description
- Details
- Materials
- Documents
- Videos
- Review
Description
FEATURES
The UltiMaker PVA Removal Station is the ultimate 3D printing support removal tool, designed to make dissolving PVA supports faster and easier. This precision-engineered solution allows you to produce complex parts and stunning prototypes more efficiently by removing support material in a matter of hours.
Key features include:
- Rinsing basket dimensions of 200 x 230 x 165 mm, perfect for a variety of print sizes
- Rotor-powered water circulation with adjustable speed settings, ensuring effective and consistent PVA removal
- Minimal maintenance required, making it easy to use and maintain
- Up to 4x faster removal of PVA compared to traditional soaking in motionless water
- With the UltiMaker PVA Removal Station, you can streamline your 3D printing workflow, achieving faster design iterations with minimal operator time. It’s an essential tool for anyone looking to improve efficiency and accuracy in their post-processing.
Simple post-processing. Faster Shrink your post-processing time
High-speed water circulation driven by a magnetic rotor removes PVA up to four times faster than motionless water, even from hard-to-reach cavities. So you have your parts post-processed and ready to use as soon as possible.
Reduce operator time up to 80%
The UltiMaker PVA Removal Station requires only a few minutes of operator time per print, with minimal maintenance needs. Just press the start button, leave it to do its job, and collect your print when it’s ready.
Compared with dissolving PVA in motionless water in an improvised container
Rotor-powered water circulation
Choose 100 or 225 RPM circulation depending on the fragility of your part. Every two minutes, the rotor changes direction to push water evenly against the model.
Prints stay safe and submerged
A rinsing basket keeps your print in place and completely submerged while dissolving, then lifts up for mess-free draining and print removal.
Easy to monitor progress
A transparent, illuminated container lets you easily follow the PVA removal process and see when your part is ready. Plus, a saturation indicator shows when to refresh the water.
- Brand UltiMaker
- Container volume 13.7 liters (3.6 US gal)
- Maximum part size W 200 x D 230 x H 165 mm (W 7.8 x D 9 x H 6.4 in)
- Supported materials Optimized for: PLA and PVA Also suitable for: PETG, Tough PLA, Nylon, or CPE in combination with PVA (Also supports equivalent third-party materials)
- Technology FFF
- Rotor speed 225 RPM (normal) 100 RPM (low)
- Operating ambient temperature 15 - 32 °C (59 - 90 °F)
- Power Consumption 38 W
